LR35902 扩展指令集

标准的算术逻辑指令通常将结果写回到寄存器 A. 它们所完成任务可以用如下语言描述: 从寄存器 A 拿出数据, 进行一些算术逻辑运算后再重新放回寄存器 A. 想象一下下面这个需求: 对寄存器 B 内存储的数据右移一位. 如下的操作步骤是一个可行的方案:

  1. 将寄存器 A 的值保存到内存中.
  2. 将寄存器 B 的值保存到寄存器 A.
  3. 将寄存器 A 右移一位.
  4. 将寄存器 A 的值保存到寄存器 B.
  5. 将第一步保存的值写回寄存器 A.

这样操作显得有点麻烦, 如果可以直接对寄存器 B 的数据进行位移运算就好了! 但是 LR35902 是 8 位 CPU, 因此如果使用一个 Byte 来表示一个操作码的话, 其最多只允许表示 2^8 = 256 个指令, 如果读者曾注意上一节中标准指令集的操作码个数的话, 会发现单单标准指令集就已经有接近 256 个了. 现在已经没有足够的空位来为不同的寄存器都实现算术逻辑指令, 那么, 是否可以将指令扩展到两个 Byte?

什么是扩展指令集

扩展指令集是指为 CPU 增加新的指令集, 这些扩展指令可以提高 CPU 处理数学运算的能力. 在现代 CPU 中, 常见的有 MMX, SSE 等扩展指令集. 一个早期的比较著名的扩展指令集出现在上世纪 70 年代的街机游戏太空侵略者(其游戏画面如下图所示), 该街机使用 Intel 8080 CPU, 但 Intel 8080 CPU 的标准指令集不带数字的移位指令, 因此该街机选择通过外接硬件电路, 通过 CPU I/O 串口来实现移位操作.


LR35902 的扩展指令大小是两个 Byte, 其中第一个 Byte 固定是 0xcb. 因此在实现过程中, 如果发现取得的指令是 0xcb, 则需要继续取一个 Byte. 代码实现如下:

fn ex(&mut self) -> u32 {
    let opcode = self.imm();
    match opcode {
        0xcb => {
            cbcode = self.mem.borrow().get(self.reg.pc);
            self.reg.pc += 1;
            match cbcode {
                ...
            }
        }
        ...
    }
}

下面给出了扩展指令的摘要以及仿真实现. 如果该指令影响了标志位, 则会在指令描述中指明.

循环和移位操作

RLC r8

1) 描述

目标寄存器按位左移. 最高位移动至溢出标志位.

2) 标志位变化

  • Z - 计算结果为零, 则置位
  • N - 置零
  • H - 置零
  • C - 原始值的最高位.

3) 指令

Instruction Parameters Opcode Cycles
RLC B 00 8
RLC C 01 8
RLC D 02 8
RLC E 03 8
RLC H 04 8
RLC L 05 8
RLC (HL) 06 16
RLC A 07 8

4) 代码实现

fn ex(&mut self) -> u32 {
    let opcode = self.imm();
    match opcode {
        0xcb => {
            cbcode = self.mem.borrow().get(self.reg.pc);
            self.reg.pc += 1;
            match cbcode {
                0x00 => self.reg.b = self.alu_rlc(self.reg.b),
                0x01 => self.reg.c = self.alu_rlc(self.reg.c),
                0x02 => self.reg.d = self.alu_rlc(self.reg.d),
                0x03 => self.reg.e = self.alu_rlc(self.reg.e),
                0x04 => self.reg.h = self.alu_rlc(self.reg.h),
                0x05 => self.reg.l = self.alu_rlc(self.reg.l),
                0x06 => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_rlc(v);
                    self.mem.borrow_mut().set(a, h);
                }
                0x07 => self.reg.a = self.alu_rlc(self.reg.a),
                ...
            }
        }
        ...
    }
}

RRC r8

1) 描述

目标寄存器按位右移. 最低位移动至溢出标志位.

2) 标志位变化

  • Z - 计算结果为零, 则置位
  • N - 置零
  • H - 置零
  • C - 原始值的最低位

3) 指令

Instruction Parameters Opcode Cycles
RRC B 08 8
RRC C 09 8
RRC D 0a 8
RRC E 0b 8
RRC H 0c 8
RRC L 0d 8
RRC (HL) 0e 16
RRC A 0f 8

4) 代码实现

fn ex(&mut self) -> u32 {
    let opcode = self.imm();
    match opcode {
        0xcb => {
            cbcode = self.mem.borrow().get(self.reg.pc);
            self.reg.pc += 1;
            match cbcode {
                0x08 => self.reg.b = self.alu_rrc(self.reg.b),
                0x09 => self.reg.c = self.alu_rrc(self.reg.c),
                0x0a => self.reg.d = self.alu_rrc(self.reg.d),
                0x0b => self.reg.e = self.alu_rrc(self.reg.e),
                0x0c => self.reg.h = self.alu_rrc(self.reg.h),
                0x0d => self.reg.l = self.alu_rrc(self.reg.l),
                0x0e => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_rrc(v);
                    self.mem.borrow_mut().set(a, h);
                }
                0x0f => self.reg.a = self.alu_rrc(self.reg.a),
                ...
            }
        }
        ...
    }
}

RL r8

1) 描述

目标寄存器按位左移运算. 溢出标志位补充最低位, 同时最高位移动至溢出标志位.

2) 标志位变化

  • Z - 计算结果为零, 则置位
  • N - 置零
  • H - 置零
  • C - 原始值的最高位.

3) 指令

Instruction Parameters Opcode Cycles
RL B 10 8
RL C 11 8
RL D 12 8
RL E 13 8
RL H 14 8
RL L 15 8
RL (HL) 16 16
RL A 17 8

4) 代码实现

fn ex(&mut self) -> u32 {
    let opcode = self.imm();
    match opcode {
        0xcb => {
            cbcode = self.mem.borrow().get(self.reg.pc);
            self.reg.pc += 1;
            match cbcode {
                0x10 => self.reg.b = self.alu_rl(self.reg.b),
                0x11 => self.reg.c = self.alu_rl(self.reg.c),
                0x12 => self.reg.d = self.alu_rl(self.reg.d),
                0x13 => self.reg.e = self.alu_rl(self.reg.e),
                0x14 => self.reg.h = self.alu_rl(self.reg.h),
                0x15 => self.reg.l = self.alu_rl(self.reg.l),
                0x16 => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_rl(v);
                    self.mem.borrow_mut().set(a, h);
                }
                0x17 => self.reg.a = self.alu_rl(self.reg.a),
                ...
            }
        }
        ...
    }
}

RR r8

1) 描述

目标寄存器按位右移运算. 溢出标志位移动至最高位, 同时最低位移动至溢出标志位.

2) 标志位变化

  • Z - 计算结果为零, 则置位
  • N - 置零
  • H - 置零
  • C - 原始数据最低位

3) 指令

Instruction Parameters Opcode Cycles
RR B 18 8
RR C 19 8
RR D 1a 8
RR E 1b 8
RR H 1c 8
RR L 1d 8
RR (HL) 1e 16
RR A 1f 8

4) 代码实现

fn ex(&mut self) -> u32 {
    let opcode = self.imm();
    match opcode {
        0xcb => {
            cbcode = self.mem.borrow().get(self.reg.pc);
            self.reg.pc += 1;
            match cbcode {
                0x18 => self.reg.b = self.alu_rr(self.reg.b),
                0x19 => self.reg.c = self.alu_rr(self.reg.c),
                0x1a => self.reg.d = self.alu_rr(self.reg.d),
                0x1b => self.reg.e = self.alu_rr(self.reg.e),
                0x1c => self.reg.h = self.alu_rr(self.reg.h),
                0x1d => self.reg.l = self.alu_rr(self.reg.l),
                0x1e => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_rr(v);
                    self.mem.borrow_mut().set(a, h);
                }
                0x1f => self.reg.a = self.alu_rr(self.reg.a),
                ...
            }
        }
        ...
    }
}

SLA r8

1) 描述

目标寄存器按位左移运算. 最高位移动至溢出标志位, 最低位设置为零.

2) 标志位变化

  • Z - 计算结果为零, 则置位
  • N - 置零
  • H - 置零
  • C - 原始数据最高位

3) 指令

Instruction Parameters Opcode Cycles
SLA B 20 8
SLA C 21 8
SLA D 22 8
SLA E 23 8
SLA H 24 8
SLA L 25 8
SLA (HL) 26 16
SLA A 27 8

4) 代码实现

impl Cpu {
    // Shift n left into Carry. LSB of n set to 0.
    // n = A,B,C,D,E,H,L,(HL)
    //
    // Flags affected:
    // Z - Set if result is zero.
    // N - Reset.
    // H - Reset.
    // C - Contains old bit 7 data
    fn alu_sla(&mut self, a: u8) -> u8 {
        let c = (a & 0x80) >> 7 == 0x01;
        let r = a << 1;
        self.reg.set_flag(C, c);
        self.reg.set_flag(H, false);
        self.reg.set_flag(N, false);
        self.reg.set_flag(Z, r == 0x00);
        r
    }
}

fn ex(&mut self) -> u32 {
    let opcode = self.imm();
    match opcode {
        0xcb => {
            cbcode = self.mem.borrow().get(self.reg.pc);
            self.reg.pc += 1;
            match cbcode {
                0x20 => self.reg.b = self.alu_sla(self.reg.b),
                0x21 => self.reg.c = self.alu_sla(self.reg.c),
                0x22 => self.reg.d = self.alu_sla(self.reg.d),
                0x23 => self.reg.e = self.alu_sla(self.reg.e),
                0x24 => self.reg.h = self.alu_sla(self.reg.h),
                0x25 => self.reg.l = self.alu_sla(self.reg.l),
                0x26 => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_sla(v);
                    self.mem.borrow_mut().set(a, h);
                }
                0x27 => self.reg.a = self.alu_sla(self.reg.a),
                ...
            }
        }
        ...
    }
}

SRA r8

1) 描述

目标寄存器按位右移运算. 最低位保存入溢出标志位, 最高位保持不变.

2) 标志位变化

  • Z - 计算结果为零, 则置位
  • N - 置零
  • H - 置零
  • C - 原始数据最低位

3) 指令

Instruction Parameters Opcode Cycles
SRA B 28 8
SRA C 29 8
SRA D 2a 8
SRA E 2b 8
SRA H 2c 8
SRA L 2d 8
SRA (HL) 2e 16
SRA A 2f 8

4) 代码实现

impl Cpu {
    // Shift n right into Carry. MSB doesn't change.
    // n = A,B,C,D,E,H,L,(HL)
    //
    // Flags affected:
    // Z - Set if result is zero.
    // N - Reset.
    // H - Reset.
    // C - Contains old bit 0 data.
    fn alu_sra(&mut self, a: u8) -> u8 {
        let c = a & 0x01 == 0x01;
        let r = (a >> 1) | (a & 0x80);
        self.reg.set_flag(C, c);
        self.reg.set_flag(H, false);
        self.reg.set_flag(N, false);
        self.reg.set_flag(Z, r == 0x00);
        r
    }
}

fn ex(&mut self) -> u32 {
    let opcode = self.imm();
    match opcode {
        0xcb => {
            cbcode = self.mem.borrow().get(self.reg.pc);
            self.reg.pc += 1;
            match cbcode {
                0x28 => self.reg.b = self.alu_sra(self.reg.b),
                0x29 => self.reg.c = self.alu_sra(self.reg.c),
                0x2a => self.reg.d = self.alu_sra(self.reg.d),
                0x2b => self.reg.e = self.alu_sra(self.reg.e),
                0x2c => self.reg.h = self.alu_sra(self.reg.h),
                0x2d => self.reg.l = self.alu_sra(self.reg.l),
                0x2e => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_sra(v);
                    self.mem.borrow_mut().set(a, h);
                }
                0x2f => self.reg.a = self.alu_sra(self.reg.a),
                ...
            }
        }
        ...
    }
}

SRL r8

1) 描述

目标寄存器按位右移运算. 最低位移动至溢出标志位, 最高位置零.

2) 标志位变化

  • Z - 计算结果为零, 则置位
  • N - 置零
  • H - 置零
  • C - 原始数据最低位

3) 指令

Instruction Parameters Opcode Cycles
SRL B 38 8
SRL C 39 8
SRL D 3a 8
SRL E 3b 8
SRL H 3c 8
SRL L 3d 8
SRL (HL) 3e 16
SRL A 3f 8

4) 代码实现

impl Cpu {
    // Shift n right into Carry. MSB set to 0.
    // n = A,B,C,D,E,H,L,(HL)
    //
    // Flags affected:
    // Z - Set if result is zero.
    // N - Reset.
    // H - Reset.
    // C - Contains old bit 0 data.
    fn alu_srl(&mut self, a: u8) -> u8 {
        let c = a & 0x01 == 0x01;
        let r = a >> 1;
        self.reg.set_flag(C, c);
        self.reg.set_flag(H, false);
        self.reg.set_flag(N, false);
        self.reg.set_flag(Z, r == 0x00);
        r
    }
}

fn ex(&mut self) -> u32 {
    let opcode = self.imm();
    match opcode {
        0xcb => {
            cbcode = self.mem.borrow().get(self.reg.pc);
            self.reg.pc += 1;
            match cbcode {
                0x38 => self.reg.b = self.alu_srl(self.reg.b),
                0x39 => self.reg.c = self.alu_srl(self.reg.c),
                0x3a => self.reg.d = self.alu_srl(self.reg.d),
                0x3b => self.reg.e = self.alu_srl(self.reg.e),
                0x3c => self.reg.h = self.alu_srl(self.reg.h),
                0x3d => self.reg.l = self.alu_srl(self.reg.l),
                0x3e => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_srl(v);
                    self.mem.borrow_mut().set(a, h);
                }
                0x3f => self.reg.a = self.alu_srl(self.reg.a),
                ...
            }
        }
        ...
    }
}

交换

SWAP r8

1) 描述

交换目标寄存器高 4 位与低 4 位的比特.

2) 标志位变化

  • Z - 计算结果为零, 则置位
  • N - 置零
  • H - 置零
  • C - 置零

3) 指令

Instruction Parameters Opcode Cycles
SWAP B 30 8
SWAP C 31 8
SWAP D 32 8
SWAP E 33 8
SWAP H 34 8
SWAP L 35 8
SWAP (HL) 36 16
SWAP A 37 8

4) 代码实现

impl Cpu {
    // Swap upper & lower nibles of n.
    // n = A,B,C,D,E,H,L,(HL)
    //
    // Flags affected:
    // Z - Set if result is zero.
    // N - Reset.
    // H - Reset.
    // C - Reset.
    fn alu_swap(&mut self, a: u8) -> u8 {
        self.reg.set_flag(C, false);
        self.reg.set_flag(H, false);
        self.reg.set_flag(N, false);
        self.reg.set_flag(Z, a == 0x00);
        (a >> 4) | (a << 4)
    }
}

fn ex(&mut self) -> u32 {
    let opcode = self.imm();
    match opcode {
        0xcb => {
            cbcode = self.mem.borrow().get(self.reg.pc);
            self.reg.pc += 1;
            match cbcode {
                0x30 => self.reg.b = self.alu_swap(self.reg.b),
                0x31 => self.reg.c = self.alu_swap(self.reg.c),
                0x32 => self.reg.d = self.alu_swap(self.reg.d),
                0x33 => self.reg.e = self.alu_swap(self.reg.e),
                0x34 => self.reg.h = self.alu_swap(self.reg.h),
                0x35 => self.reg.l = self.alu_swap(self.reg.l),
                0x36 => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_swap(v);
                    self.mem.borrow_mut().set(a, h);
                }
                0x37 => self.reg.a = self.alu_swap(self.reg.a),
                ...
            }
        }
        ...
    }
}

位数据获取与设置

BIT

1) 描述

取得目标寄存器中指定的 bit 位.

2) 标志位变化

  • Z - 如果指定寄存器的指定 bit 位为零, 则置零.
  • N - 置零
  • H - 置位
  • C - 保持不变

3) 指令

Instruction Parameters Opcode Cycles
BIT B, 0 40 8
BIT C, 0 41 8
BIT D, 0 42 8
BIT E, 0 43 8
BIT H, 0 44 8
BIT L, 0 45 8
BIT (HL), 0 46 16
BIT A, 0 47 8
BIT B, 1 48 8
BIT C, 1 49 8
BIT D, 1 4a 8
BIT E, 1 4b 8
BIT H, 1 4c 8
BIT L, 1 4d 8
BIT (HL), 1 4e 16
BIT A, 1 4f 8
BIT B, 2 50 8
BIT C, 2 51 8
BIT D, 2 52 8
BIT E, 2 53 8
BIT H, 2 54 8
BIT L, 2 55 8
BIT (HL), 2 56 16
BIT A, 2 57 8
BIT B, 3 58 8
BIT C, 3 59 8
BIT D, 3 5a 8
BIT E, 3 5b 8
BIT H, 3 5c 8
BIT L, 3 5d 8
BIT (HL), 3 5e 16
BIT A, 3 5f 8
BIT B, 4 60 8
BIT C, 4 61 8
BIT D, 4 62 8
BIT E, 4 63 8
BIT H, 4 64 8
BIT L, 4 65 8
BIT (HL), 4 66 16
BIT A, 4 67 8
BIT B, 5 68 8
BIT C, 5 69 8
BIT D, 5 6a 8
BIT E, 5 6b 8
BIT H, 5 6c 8
BIT L, 5 6d 8
BIT (HL), 5 6e 16
BIT A, 5 6f 8
BIT B, 6 70 8
BIT C, 6 71 8
BIT D, 6 72 8
BIT E, 6 73 8
BIT H, 6 74 8
BIT L, 6 75 8
BIT (HL), 6 76 16
BIT A, 6 77 8
BIT B, 7 78 8
BIT C, 7 79 8
BIT D, 7 7a 8
BIT E, 7 7b 8
BIT H, 7 7c 8
BIT L, 7 7d 8
BIT (HL), 7 7e 16
BIT A, 7 7f 8

4) 代码实现

impl Cpu {
    // Test bit b in register r.
    // b = 0 - 7, r = A,B,C,D,E,H,L,(HL)
    //
    // Flags affected:
    // Z - Set if bit b of register r is 0.
    // N - Reset.
    // H - Set.
    // C - Not affected
    fn alu_bit(&mut self, a: u8, b: u8) {
        let r = a & (1 << b) == 0x00;
        self.reg.set_flag(H, true);
        self.reg.set_flag(N, false);
        self.reg.set_flag(Z, r);
    }
}

fn ex(&mut self) -> u32 {
    let opcode = self.imm();
    match opcode {
        0xcb => {
            cbcode = self.mem.borrow().get(self.reg.pc);
            self.reg.pc += 1;
            match cbcode {
                0x40 => self.alu_bit(self.reg.b, 0),
                0x41 => self.alu_bit(self.reg.c, 0),
                0x42 => self.alu_bit(self.reg.d, 0),
                0x43 => self.alu_bit(self.reg.e, 0),
                0x44 => self.alu_bit(self.reg.h, 0),
                0x45 => self.alu_bit(self.reg.l, 0),
                0x46 => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    self.alu_bit(v, 0);
                }
                0x47 => self.alu_bit(self.reg.a, 0),
                0x48 => self.alu_bit(self.reg.b, 1),
                0x49 => self.alu_bit(self.reg.c, 1),
                0x4a => self.alu_bit(self.reg.d, 1),
                0x4b => self.alu_bit(self.reg.e, 1),
                0x4c => self.alu_bit(self.reg.h, 1),
                0x4d => self.alu_bit(self.reg.l, 1),
                0x4e => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    self.alu_bit(v, 1);
                }
                0x4f => self.alu_bit(self.reg.a, 1),
                0x50 => self.alu_bit(self.reg.b, 2),
                0x51 => self.alu_bit(self.reg.c, 2),
                0x52 => self.alu_bit(self.reg.d, 2),
                0x53 => self.alu_bit(self.reg.e, 2),
                0x54 => self.alu_bit(self.reg.h, 2),
                0x55 => self.alu_bit(self.reg.l, 2),
                0x56 => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    self.alu_bit(v, 2);
                }
                0x57 => self.alu_bit(self.reg.a, 2),
                0x58 => self.alu_bit(self.reg.b, 3),
                0x59 => self.alu_bit(self.reg.c, 3),
                0x5a => self.alu_bit(self.reg.d, 3),
                0x5b => self.alu_bit(self.reg.e, 3),
                0x5c => self.alu_bit(self.reg.h, 3),
                0x5d => self.alu_bit(self.reg.l, 3),
                0x5e => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    self.alu_bit(v, 3);
                }
                0x5f => self.alu_bit(self.reg.a, 3),
                0x60 => self.alu_bit(self.reg.b, 4),
                0x61 => self.alu_bit(self.reg.c, 4),
                0x62 => self.alu_bit(self.reg.d, 4),
                0x63 => self.alu_bit(self.reg.e, 4),
                0x64 => self.alu_bit(self.reg.h, 4),
                0x65 => self.alu_bit(self.reg.l, 4),
                0x66 => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    self.alu_bit(v, 4);
                }
                0x67 => self.alu_bit(self.reg.a, 4),
                0x68 => self.alu_bit(self.reg.b, 5),
                0x69 => self.alu_bit(self.reg.c, 5),
                0x6a => self.alu_bit(self.reg.d, 5),
                0x6b => self.alu_bit(self.reg.e, 5),
                0x6c => self.alu_bit(self.reg.h, 5),
                0x6d => self.alu_bit(self.reg.l, 5),
                0x6e => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    self.alu_bit(v, 5);
                }
                0x6f => self.alu_bit(self.reg.a, 5),
                0x70 => self.alu_bit(self.reg.b, 6),
                0x71 => self.alu_bit(self.reg.c, 6),
                0x72 => self.alu_bit(self.reg.d, 6),
                0x73 => self.alu_bit(self.reg.e, 6),
                0x74 => self.alu_bit(self.reg.h, 6),
                0x75 => self.alu_bit(self.reg.l, 6),
                0x76 => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    self.alu_bit(v, 6);
                }
                0x77 => self.alu_bit(self.reg.a, 6),
                0x78 => self.alu_bit(self.reg.b, 7),
                0x79 => self.alu_bit(self.reg.c, 7),
                0x7a => self.alu_bit(self.reg.d, 7),
                0x7b => self.alu_bit(self.reg.e, 7),
                0x7c => self.alu_bit(self.reg.h, 7),
                0x7d => self.alu_bit(self.reg.l, 7),
                0x7e => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    self.alu_bit(v, 7);
                }
                0x7f => self.alu_bit(self.reg.a, 7),
                ...
            }
        }
        ...
    }
}

RES

1) 描述

置零目标寄存器中指定的 bit 位.

2) 标志位变化

3) 指令

Instruction Parameters Opcode Cycles
RES B, 0 80 8
RES C, 0 81 8
RES D, 0 82 8
RES E, 0 83 8
RES H, 0 84 8
RES L, 0 85 8
RES (HL), 0 86 16
RES A, 0 87 8
RES B, 1 88 8
RES C, 1 89 8
RES D, 1 8a 8
RES E, 1 8b 8
RES H, 1 8c 8
RES L, 1 8d 8
RES (HL), 1 8e 16
RES A, 1 8f 8
RES B, 2 90 8
RES C, 2 91 8
RES D, 2 92 8
RES E, 2 93 8
RES H, 2 94 8
RES L, 2 95 8
RES (HL), 2 96 16
RES A, 2 97 8
RES B, 3 98 8
RES C, 3 99 8
RES D, 3 9a 8
RES E, 3 9b 8
RES H, 3 9c 8
RES L, 3 9d 8
RES (HL), 3 9e 16
RES A, 3 9f 8
RES B, 4 a0 8
RES C, 4 a1 8
RES D, 4 a2 8
RES E, 4 a3 8
RES H, 4 a4 8
RES L, 4 a5 8
RES (HL), 4 a6 16
RES A, 4 a7 8
RES B, 5 a8 8
RES C, 5 a9 8
RES D, 5 aa 8
RES E, 5 ab 8
RES H, 5 ac 8
RES L, 5 ad 8
RES (HL), 5 ae 16
RES A, 5 af 8
RES B, 6 b0 8
RES C, 6 b1 8
RES D, 6 b2 8
RES E, 6 b3 8
RES H, 6 b4 8
RES L, 6 b5 8
RES (HL), 6 b6 16
RES A, 6 b7 8
RES B, 7 b8 8
RES C, 7 b9 8
RES D, 7 ba 8
RES E, 7 bb 8
RES H, 7 bc 8
RES L, 7 bd 8
RES (HL), 7 be 16
RES A, 7 bf 8

4) 代码实现

impl Cpu {
    // Reset bit b in register r.
    // b = 0 - 7, r = A,B,C,D,E,H,L,(HL)
    //
    // Flags affected:  None.
    fn alu_res(&mut self, a: u8, b: u8) -> u8 {
        a & !(1 << b)
    }
}

fn ex(&mut self) -> u32 {
    let opcode = self.imm();
    match opcode {
        0xcb => {
            cbcode = self.mem.borrow().get(self.reg.pc);
            self.reg.pc += 1;
            match cbcode {
                0x80 => self.reg.b = self.alu_res(self.reg.b, 0),
                0x81 => self.reg.c = self.alu_res(self.reg.c, 0),
                0x82 => self.reg.d = self.alu_res(self.reg.d, 0),
                0x83 => self.reg.e = self.alu_res(self.reg.e, 0),
                0x84 => self.reg.h = self.alu_res(self.reg.h, 0),
                0x85 => self.reg.l = self.alu_res(self.reg.l, 0),
                0x86 => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_res(v, 0);
                    self.mem.borrow_mut().set(a, h);
                }
                0x87 => self.reg.a = self.alu_res(self.reg.a, 0),
                0x88 => self.reg.b = self.alu_res(self.reg.b, 1),
                0x89 => self.reg.c = self.alu_res(self.reg.c, 1),
                0x8a => self.reg.d = self.alu_res(self.reg.d, 1),
                0x8b => self.reg.e = self.alu_res(self.reg.e, 1),
                0x8c => self.reg.h = self.alu_res(self.reg.h, 1),
                0x8d => self.reg.l = self.alu_res(self.reg.l, 1),
                0x8e => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_res(v, 1);
                    self.mem.borrow_mut().set(a, h);
                }
                0x8f => self.reg.a = self.alu_res(self.reg.a, 1),
                0x90 => self.reg.b = self.alu_res(self.reg.b, 2),
                0x91 => self.reg.c = self.alu_res(self.reg.c, 2),
                0x92 => self.reg.d = self.alu_res(self.reg.d, 2),
                0x93 => self.reg.e = self.alu_res(self.reg.e, 2),
                0x94 => self.reg.h = self.alu_res(self.reg.h, 2),
                0x95 => self.reg.l = self.alu_res(self.reg.l, 2),
                0x96 => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_res(v, 2);
                    self.mem.borrow_mut().set(a, h);
                }
                0x97 => self.reg.a = self.alu_res(self.reg.a, 2),
                0x98 => self.reg.b = self.alu_res(self.reg.b, 3),
                0x99 => self.reg.c = self.alu_res(self.reg.c, 3),
                0x9a => self.reg.d = self.alu_res(self.reg.d, 3),
                0x9b => self.reg.e = self.alu_res(self.reg.e, 3),
                0x9c => self.reg.h = self.alu_res(self.reg.h, 3),
                0x9d => self.reg.l = self.alu_res(self.reg.l, 3),
                0x9e => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_res(v, 3);
                    self.mem.borrow_mut().set(a, h);
                }
                0x9f => self.reg.a = self.alu_res(self.reg.a, 3),
                0xa0 => self.reg.b = self.alu_res(self.reg.b, 4),
                0xa1 => self.reg.c = self.alu_res(self.reg.c, 4),
                0xa2 => self.reg.d = self.alu_res(self.reg.d, 4),
                0xa3 => self.reg.e = self.alu_res(self.reg.e, 4),
                0xa4 => self.reg.h = self.alu_res(self.reg.h, 4),
                0xa5 => self.reg.l = self.alu_res(self.reg.l, 4),
                0xa6 => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_res(v, 4);
                    self.mem.borrow_mut().set(a, h);
                }
                0xa7 => self.reg.a = self.alu_res(self.reg.a, 4),
                0xa8 => self.reg.b = self.alu_res(self.reg.b, 5),
                0xa9 => self.reg.c = self.alu_res(self.reg.c, 5),
                0xaa => self.reg.d = self.alu_res(self.reg.d, 5),
                0xab => self.reg.e = self.alu_res(self.reg.e, 5),
                0xac => self.reg.h = self.alu_res(self.reg.h, 5),
                0xad => self.reg.l = self.alu_res(self.reg.l, 5),
                0xae => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_res(v, 5);
                    self.mem.borrow_mut().set(a, h);
                }
                0xaf => self.reg.a = self.alu_res(self.reg.a, 5),
                0xb0 => self.reg.b = self.alu_res(self.reg.b, 6),
                0xb1 => self.reg.c = self.alu_res(self.reg.c, 6),
                0xb2 => self.reg.d = self.alu_res(self.reg.d, 6),
                0xb3 => self.reg.e = self.alu_res(self.reg.e, 6),
                0xb4 => self.reg.h = self.alu_res(self.reg.h, 6),
                0xb5 => self.reg.l = self.alu_res(self.reg.l, 6),
                0xb6 => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_res(v, 6);
                    self.mem.borrow_mut().set(a, h);
                }
                0xb7 => self.reg.a = self.alu_res(self.reg.a, 6),
                0xb8 => self.reg.b = self.alu_res(self.reg.b, 7),
                0xb9 => self.reg.c = self.alu_res(self.reg.c, 7),
                0xba => self.reg.d = self.alu_res(self.reg.d, 7),
                0xbb => self.reg.e = self.alu_res(self.reg.e, 7),
                0xbc => self.reg.h = self.alu_res(self.reg.h, 7),
                0xbd => self.reg.l = self.alu_res(self.reg.l, 7),
                0xbe => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_res(v, 7);
                    self.mem.borrow_mut().set(a, h);
                }
                0xbf => self.reg.a = self.alu_res(self.reg.a, 7),
                ...
            }
        }
        ...
    }
}

SET

1) 描述

置位寄存器中指定的 bit 位.

2) 标志位变化

3) 指令

Instruction Parameters Opcode Cycles
SET B, 0 c0 8
SET C, 0 c1 8
SET D, 0 c2 8
SET E, 0 c3 8
SET H, 0 c4 8
SET L, 0 c5 8
SET (HL), 0 c6 16
SET A, 0 c7 8
SET B, 1 c8 8
SET C, 1 c9 8
SET D, 1 ca 8
SET E, 1 cb 8
SET H, 1 cc 8
SET L, 1 cd 8
SET (HL), 1 ce 16
SET A, 1 cf 8
SET B, 2 d0 8
SET C, 2 d1 8
SET D, 2 d2 8
SET E, 2 d3 8
SET H, 2 d4 8
SET L, 2 d5 8
SET (HL), 2 d6 16
SET A, 2 d7 8
SET B, 3 d8 8
SET C, 3 d9 8
SET D, 3 da 8
SET E, 3 db 8
SET H, 3 dc 8
SET L, 3 dd 8
SET (HL), 3 de 16
SET A, 3 df 8
SET B, 4 e0 8
SET C, 4 e1 8
SET D, 4 e2 8
SET E, 4 e3 8
SET H, 4 e4 8
SET L, 4 e5 8
SET (HL), 4 e6 16
SET A, 4 e7 8
SET B, 5 e8 8
SET C, 5 e9 8
SET D, 5 ea 8
SET E, 5 eb 8
SET H, 5 ec 8
SET L, 5 ed 8
SET (HL), 5 ee 16
SET A, 5 ef 8
SET B, 6 f0 8
SET C, 6 f1 8
SET D, 6 f2 8
SET E, 6 f3 8
SET H, 6 f4 8
SET L, 6 f5 8
SET (HL), 6 f6 16
SET A, 6 f7 8
SET B, 7 f8 8
SET C, 7 f9 8
SET D, 7 fa 8
SET E, 7 fb 8
SET H, 7 fc 8
SET L, 7 fd 8
SET (HL), 7 fe 16
SET A, 7 ff 8

4) 代码实现

impl Cpu {
    // Set bit b in register r.
    // b = 0 - 7, r = A,B,C,D,E,H,L,(HL)
    //
    // Flags affected:  None.
    fn alu_set(&mut self, a: u8, b: u8) -> u8 {
        a | (1 << b)
    }
}

fn ex(&mut self) -> u32 {
    let opcode = self.imm();
    match opcode {
        0xcb => {
            cbcode = self.mem.borrow().get(self.reg.pc);
            self.reg.pc += 1;
            match cbcode {
                0xc0 => self.reg.b = self.alu_set(self.reg.b, 0),
                0xc1 => self.reg.c = self.alu_set(self.reg.c, 0),
                0xc2 => self.reg.d = self.alu_set(self.reg.d, 0),
                0xc3 => self.reg.e = self.alu_set(self.reg.e, 0),
                0xc4 => self.reg.h = self.alu_set(self.reg.h, 0),
                0xc5 => self.reg.l = self.alu_set(self.reg.l, 0),
                0xc6 => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_set(v, 0);
                    self.mem.borrow_mut().set(a, h);
                }
                0xc7 => self.reg.a = self.alu_set(self.reg.a, 0),
                0xc8 => self.reg.b = self.alu_set(self.reg.b, 1),
                0xc9 => self.reg.c = self.alu_set(self.reg.c, 1),
                0xca => self.reg.d = self.alu_set(self.reg.d, 1),
                0xcb => self.reg.e = self.alu_set(self.reg.e, 1),
                0xcc => self.reg.h = self.alu_set(self.reg.h, 1),
                0xcd => self.reg.l = self.alu_set(self.reg.l, 1),
                0xce => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_set(v, 1);
                    self.mem.borrow_mut().set(a, h);
                }
                0xcf => self.reg.a = self.alu_set(self.reg.a, 1),
                0xd0 => self.reg.b = self.alu_set(self.reg.b, 2),
                0xd1 => self.reg.c = self.alu_set(self.reg.c, 2),
                0xd2 => self.reg.d = self.alu_set(self.reg.d, 2),
                0xd3 => self.reg.e = self.alu_set(self.reg.e, 2),
                0xd4 => self.reg.h = self.alu_set(self.reg.h, 2),
                0xd5 => self.reg.l = self.alu_set(self.reg.l, 2),
                0xd6 => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_set(v, 2);
                    self.mem.borrow_mut().set(a, h);
                }
                0xd7 => self.reg.a = self.alu_set(self.reg.a, 2),
                0xd8 => self.reg.b = self.alu_set(self.reg.b, 3),
                0xd9 => self.reg.c = self.alu_set(self.reg.c, 3),
                0xda => self.reg.d = self.alu_set(self.reg.d, 3),
                0xdb => self.reg.e = self.alu_set(self.reg.e, 3),
                0xdc => self.reg.h = self.alu_set(self.reg.h, 3),
                0xdd => self.reg.l = self.alu_set(self.reg.l, 3),
                0xde => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_set(v, 3);
                    self.mem.borrow_mut().set(a, h);
                }
                0xdf => self.reg.a = self.alu_set(self.reg.a, 3),
                0xe0 => self.reg.b = self.alu_set(self.reg.b, 4),
                0xe1 => self.reg.c = self.alu_set(self.reg.c, 4),
                0xe2 => self.reg.d = self.alu_set(self.reg.d, 4),
                0xe3 => self.reg.e = self.alu_set(self.reg.e, 4),
                0xe4 => self.reg.h = self.alu_set(self.reg.h, 4),
                0xe5 => self.reg.l = self.alu_set(self.reg.l, 4),
                0xe6 => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_set(v, 4);
                    self.mem.borrow_mut().set(a, h);
                }
                0xe7 => self.reg.a = self.alu_set(self.reg.a, 4),
                0xe8 => self.reg.b = self.alu_set(self.reg.b, 5),
                0xe9 => self.reg.c = self.alu_set(self.reg.c, 5),
                0xea => self.reg.d = self.alu_set(self.reg.d, 5),
                0xeb => self.reg.e = self.alu_set(self.reg.e, 5),
                0xec => self.reg.h = self.alu_set(self.reg.h, 5),
                0xed => self.reg.l = self.alu_set(self.reg.l, 5),
                0xee => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_set(v, 5);
                    self.mem.borrow_mut().set(a, h);
                }
                0xef => self.reg.a = self.alu_set(self.reg.a, 5),
                0xf0 => self.reg.b = self.alu_set(self.reg.b, 6),
                0xf1 => self.reg.c = self.alu_set(self.reg.c, 6),
                0xf2 => self.reg.d = self.alu_set(self.reg.d, 6),
                0xf3 => self.reg.e = self.alu_set(self.reg.e, 6),
                0xf4 => self.reg.h = self.alu_set(self.reg.h, 6),
                0xf5 => self.reg.l = self.alu_set(self.reg.l, 6),
                0xf6 => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_set(v, 6);
                    self.mem.borrow_mut().set(a, h);
                }
                0xf7 => self.reg.a = self.alu_set(self.reg.a, 6),
                0xf8 => self.reg.b = self.alu_set(self.reg.b, 7),
                0xf9 => self.reg.c = self.alu_set(self.reg.c, 7),
                0xfa => self.reg.d = self.alu_set(self.reg.d, 7),
                0xfb => self.reg.e = self.alu_set(self.reg.e, 7),
                0xfc => self.reg.h = self.alu_set(self.reg.h, 7),
                0xfd => self.reg.l = self.alu_set(self.reg.l, 7),
                0xfe => {
                    let a = self.reg.get_hl();
                    let v = self.mem.borrow().get(a);
                    let h = self.alu_set(v, 7);
                    self.mem.borrow_mut().set(a, h);
                }
                0xff => self.reg.a = self.alu_set(self.reg.a, 7),
                ...
            }
        }
        ...
    }
}
